E-METRIX® Panel Wall, Block Wall & Floor Systems

AAC Systems for Low-rise building applications

E‑METRIX® Introduction

 E‑METRIX® reinforced autoclaved aerated concrete (AAC) panels are engineered for modern construction environments where reliability, speed, and consistency matter. Designed for both external and internal wall applications across low‑rise and high‑rise projects, E‑METRIX® delivers dependable performance without unnecessary weight or brittleness.

Manufactured in a fully automated Hess German‑engineered production line, every panel is produced with tight tolerances, consistent density, and repeatable accuracy. This precision gives builders, architects, and installers confidence in panel fit, finish, and long‑term durability.

With strong fire performance, thermal efficiency, and acoustic control, E‑METRIX® panels provide a balanced solution that supports compliance while helping projects stay on schedule. Their optimised weight profile — lighter than heavy AAC alternatives yet stronger than ultra‑light brittle options — makes handling and installation faster and more manageable on site.

E-METRIX® 75mm Reinforced AAC Wall Panels

Purpose‑built for low‑rise residential and multi‑residential construction, the E‑METRIX® 75 mm panel range offers a practical blend of strength, speed, and finish quality. The panels are lightweight enough for efficient installation yet robust enough to deliver reliable on‑wall performance.

Builders & Architects choose E-METRIX®

Built Strong, Built Light – Our 75 mm steel‑reinforced AAC panels combine reduced structural load with robust on‑wall performance — ideal for modern framing systems and efficient structural design. Our 75 mm steel‑reinforced AAC panels are tested by Construction Science — NATA accredited. Verified compressive strength 5.5 MPa, reliable modulus performance, and certified pull‑out results give builders confidence the panels stay solid on the wall.

Faster Builds – Panelised wall systems can significantly reduce installation time compared with traditional masonry, helping construction programs stay on track.

Thermally Efficient – AAC’s insulating cellular structure supports more stable indoor temperatures and improved energy‑efficiency outcomes across seasonal conditions. Thermal modelling by James Fricker Consulting Engineers confirms strong energy performance and comfortable living environments.Panel only (75mm) R ≈ 0.50-0.60 (at 4% moisture content). System R‑value (full wall build‑up): R2.4 ≈ R3.6 depending on insulation and lining choices

Quiet Between Homes – Reinforced AAC walls help reduce external noise transfer, supporting quieter, more comfortable interior environments. around Rw 33–35 as a single panel.Intertenancy wall system acoustic rating Rw + Ctr = 56, modelled by Resonate Acoustic Consultants. Exceeds NCC acoustic requirements for attached and multi‑residential builds.

Fire Safe Confidence – AAC is naturally non‑combustible. When used in properly tested wall systems, it can deliver strong fire‑resistance performance suitable for low‑rise applications NCC Minimum FRL: 60/60/60 for low‑rise external walls E-METRIX -/90/90. Full fire testing completed by Ignis Labs (NATA accredited). System FRL: -/90/90 Strong fire performance for compliant lightweight wall systems.

Weathering – Compliance with NCC weatherproofing requirements is achieved through the complete E‑METRIX wall system, including panel installation, joint treatment, flashings and specified coatings, as detailed in the E-METRIX TECH manual.

Design Versatility Compatible with a wide range of exterior coatings and textures, including modern rendered architectural finishes. Dulux Acratex® System recommended.

Product Snapshot

E‑METRIX® Reinforced AAC Wall Panel

Dimensions

– Thickness: 75 mm
– Width: 600 mm
– Standard Lengths: 2400 mm, 2550 mm, 2700 mm, 2850 mm, 3000 mm, 3300 mm

Material Properties

– Density for purpose is 700kg/m3 @30% moisture
– Density- Design handling & install: 520 kg/m³ Dry Density 490 kg/m³
– Compressive Strength: 5.5 MPa
– Panel Weight 2.4m x 60 x 75mm: 58 kg 
– Panel weight 3m x 600 x 75mm  72kg
– Reinforcement: 5mm steal transfer bars x 4
– Fire Resistance Level (FRL): - / 90 / 90 (tested wall system performance)

Design Intent

To provide builders, architects, and distributors with a structurally dependable, installer‑friendly AAC solution that supports compliant wall systems and modern façade design across low‑rise and multi‑residential construction.

Typical Applications

Detached Homes – Lightweight, strong panels ideal for external and internal walls, helping builders achieve modern façades with dependable fire, acoustic, and thermal performance.

Duplex & Dual‑Occupancy Projects – Streamlined walling system supports efficient construction and consistent rendered finishes across adjoining dwellings.

Townhouses – Panelised design accelerates installation while maintaining structural integrity and compliance for multi‑unit developments.

Low‑Rise Multi‑Residential Developments – Reliable performance for façades and intertenancy walls where acoustic and fire ratings are critical.

Boundary & Intertenancy Wall Systems – Suitable for project‑specific designs requiring tested assemblies to meet acoustic and fire separation standards.

Whether used in homes, duplexes, townhouses, or low‑rise apartments, E‑METRIX® provides a streamlined walling system that supports modern façade design, consistent rendered finishes, and dependable fire, acoustic, and thermal outcomes.

Compliance & Assurance

ISO 14001 — Environmental Management

E‑METRIX® operates under an ISO 14001‑aligned Environmental Management System, ensuring responsible material sourcing, controlled manufacturing processes, and continuous improvement in environmental performance.

Our framework covers:
– Identification and control of environmental impacts
– Compliance with Australian environmental legislation
– Waste reduction and resource‑efficient production
– Ongoing monitoring and improvement of environmental outcomes

This standard underpins our commitment to sustainable, low‑impact building materials for modern construction.

ISO 9001 — Quality Management

E‑METRIX® operates under an ISO 9001‑aligned Quality Management System, ensuring consistent product performance, controlled manufacturing processes, and reliable delivery across all AAC related components.
Our framework includes:
– Documented quality controls and process consistency
– Supplier and material verification
– Product conformity and batch‑level traceability
– Continuous improvement and corrective‑action systems

This standard underpins our commitment to dependable, specification‑accurate products for builders, architects, and distributors.

Build with confidence using E-METRIX® Reinforced AAC Panel Systems

Talk to our E-METRIX® team for specifications, technical guidance, and supply support for your next low-rise project.
